The sphygmograph and the physiology of the circulation : a monograph read before the Medical Society of New Jersey, upon investigations made preparatory to a larger work on the practical value of the sphygmograph . hese, thin rubber valveshave been found to work admirably. The auriculo ventricular valve is of more easy construction,being simply a drop valve, and in this heart was made ofleather. 3d. The large Sphygmograph, for recording the workingsof this artificial organ, is so arranged that any of the tubesmay be introduced behind the tracer, near its attached ex-tremity. The tracer is two
