. Scientific American Volume 86 Number 14 (April 1902) . feet above the roof of the tunnelheading. Above the rocklies a mass of what Va.iengineers call earth, thatis to say, a loose materialconsisting of gravel, sand,clay, etc., of a consistencywhich can be easily exca-vated by pick and shovel,and which has no naturalcohesion to hold it inplace. On the Wednesday pre-ceding the day on whichthe trouble occurred, itwas noticed that therewere indications of settle-ment of the rock, and asection of rock measuringabout 3x6 feet fellthrough into the tunnel.An examination of thecavity revealed a strat
