. Electronic apparatus for biological research. Electronic apparatus and appliances; Biology -- Research. NEGATIVE VOLTAGE FEEDBACK AND THE STABILIZED GAIN AMPLIFIER output voltage d Vji^ + d Vr^. Therefore the input to the valve is the difference between the signal dVin and a fixed fraction of the output, so this is a negative feedback system, the feedback being applied round one stage only. The A A^ A2 ^3 1 5i Bi 03 Figure 11.5 is {^i{RI^ + RK))l{ra + {Rl + Rk)) and the B is RkI{Rl + Rr)- Typically Rl might be 50,000 Q, /•„ = 10,000 Q, the bias 2 volts, the anode current 2 milliamps and ^ eq
