. Development of an underwater manipulator for use on a free-swimming unmanned submersible. Manipulators (Mechanism); Oceanographic submersibles. 15. To protect the armature finish and commutator surface, place some 0.005-inch-thick plastic strips (Mylar) inside the field. They should extend above the armature for grasping and removal after motor installation.. 16. Bend the brush springs very carefully so that they remain as shown. Avoid distorting. The original spring position is shown on the opposite page. Position one set of brushes on the commutator, then gently compress the remaining brus
